Huba Control 402.9300021 Differential Pressure Transmitter | 0-10 mbar | Delhi India
Product information
The Differential Pressure Transmitters of Type 402 Are Ideal For Detecting Small Air Flows in HVAC Systems And For Measuring Low Pressures In The Environmental And Medical Sectors. Sensors Specifically Developed For Each Pressure Range Enable Physically Accurate And Long-Term Stable Measurements. They Allow For Simple And Quick Installation, Either Directly Onto a Mounting Plate Or Onto a PCB
Technical Data
Product Feature
Field Of Application
Ambient Condition
Material
Electrical Data
Approval
Installation guide
Applications
Accessories
402.9300021 Differential Pressure Transmitter By Huba Control
PRODUCT/SERVICE DESCRIPTION
THE HUBA CONTROL 402.9300021 IS A COMPACT DIFFERENTIAL PRESSURE TRANSMITTER DESIGNED FOR LOW-PRESSURE MEASUREMENT OF AIR AND NEUTRAL GASES. IT IS SUITABLE FOR HVAC, AIRFLOW MONITORING, VENTILATION, ERV SYSTEMS AND INDUSTRIAL AUTOMATION APPLICATIONS. THE MODEL IS REPORTED WITH A 0–10 MBAR RANGE, 0.5–4.5 V OUTPUT AND 10.2–33 VDC SUPPLY.
KEY FEATURES
APPLICATIONS
PRODUCT SPECIFICATIONS
| SPECIFICATION | DETAILS |
|---|---|
| BRAND | HUBA CONTROL |
| MODEL | 402.9300021 |
| PRODUCT TYPE | DIFFERENTIAL PRESSURE TRANSMITTER |
| PRESSURE RANGE | 0–10 MBAR |
| OUTPUT | 0.5–4.5 V |
| SUPPLY VOLTAGE | 10.2–33 VDC |
| RESPONSE TIME | <10 MS |
| CURRENT CONSUMPTION | <8 MA |
| MEDIA | AIR, NEUTRAL GASES |
| SENSOR WEIGHT | APPROX. 28 G |
| HOUSING MATERIAL | POLYCARBONATE (PC), POLYAMIDE (PA) |
| MEMBRANE | SILICONE |
| MEASURING ELEMENT | CERAMIC AL2O3 |
| INSTALLATION | PCB / ADAPTER / BRACKET |
| PRESSURE CONNECTION | P1 TOP, PRESSURE CONNECTIONS DOWNWARDS |
| MANUFACTURER | HUBA CONTROL |
NOTE: AVAILABLE ONLINE SOURCES SHOW SOME INCONSISTENT RANGE ENTRIES FOR THIS MODEL, INCLUDING A GENERAL 0–50 MBAR TYPE-402 RANGE. FOR THE SPECIFIC 402.9300021 PRODUCT, THE LISTINGS IDENTIFY THE RANGE AS 0–10 MBAR. PLEASE VERIFY THE ORIGINAL HUBA CONTROL DATASHEET/NAMEPLATE BEFORE FINAL TECHNICAL OR COMMERCIAL USE.
